Material:
The clamp-in installation adopted by clamp-in metal valves ensures a tight connection between the valve and the rim, making the valve system more stable and reliable. The air valve is clamped on the rim through the clamping device, which prevents the air valve from loosening or falling off during driving, and improves the safety and stability of the entire air valve system. And this design can effectively reduce or eliminate the impact of external vibration on the valve system. Because the air valve is firmly clamped on the rim, external vibration is difficult to cause the air valve to shift or deform, thus maintaining the reliability of the air valve system. Compared with other installation methods, clip-in installation is simpler and faster. Simply insert the air valve into the rim hole and clamp it on the rim through the clamping device. The installation process can be completed without complicated tools or operating steps, saving time and labor costs. And this product has wide applicability and is suitable for various types of vehicle tires, including cars, trucks, motorcycles, etc., whether it is steel rims or aluminum alloy rims, it can be easily installed and used. This wide range of applicability makes CLAMP-IN METAL VALVES one of the preferred installation methods for vehicle tire valve systems.
Detailed parameters
| TR No | Etrto No |
Rim Holes (mm/in) |
Eff. length (mm) |
| V-3 | TR33E | 11.5/.453" | Φ14x33 |
| V-4 | TE43E | 11.5/.453" | Φ14x43 |
| V-5 | TE48E | 11.5/.453" | Φ14x48 |
| V-6 | TE53E | 11.5/.453" | Φ14x53 |
| V-7 | TE63E | 11.5/.453" | Φ14x63 |
| VS-8 | TR26G | 11.5/.453" | Φ16x38 |
| VS-8-45° | WH303 | 11.5/.453" | Φ16x53/45° |
| VS-8-90° | 11.5/.453" | Φ16x63/90° | |
| 5991B | WH402 | 11.5/.453" 16/.625" | Φ19x34 |
| PVR152 | 11.5/.453" | Φ16x65/90° | |
| PVR153 | 11.5/.453" | Φ17x70/90° |
