Push To Connect, Male Pipe Thread | |||||
CODE | SIZE | L | D | L1 | SW |
EU2-2SM | 1/4" | 53.5 | 22 | 10.5 | 19 |
EU2-3SM | 3/8" | 54 | 22 | 11 | 19 |
EU2-4SM | 1/2" | 57.5 | 22 | 13.5 | 21 |
Material:
European style quick connectors are widely used in industrial and agricultural fields. These couplings are designed to quickly and safely connect and disconnect pipes, hoses, or other air delivery equipment, allowing for quick and reliable fluid transfer when needed. The connection mechanism of European quick couplings makes them an indispensable part of the air transfer system. They can be connected and disconnected in seconds with a simple operation, saving a lot of time and labor costs. At the same time, these couplings are very safe. And it can maintain gas integrity when connected, reduce the risk of leakage and ensure the safe operation of the system. The entire body is made of durable materials, which can withstand long-term use in harsh working environments without being easily damaged.
Additionally, we offer a wide range of models and sizes to suit a variety of duct sizes and air delivery systems, providing a wide range of applicability.
Quick connect coupler with European (universal) standard profile.
Interchangeable with the most popular connection nipples.
Modern CNC machine tools manufactured and performed
For ease assembling and time saving applications.
Operating Temperature:-10°C to +60°C
Operating Pressure: 0-16 bar
Interchangeability: GAV 4500, UNI Series, Euro Line
Detailed parameters
Push To Connect, Male Pipe Thread | |||||
CODE | SIZE | L | D | L1 | SW |
EU2-2SM | 1/4" | 53.5 | 22 | 10.5 | 19 |
EU2-3SM | 3/8" | 54 | 22 | 11 | 19 |
EU2-4SM | 1/2" | 57.5 | 22 | 13.5 | 21 |
Push To Connect, Female Pipe Thread | |||||
CODE | SIZE | L | D | L1 | SW |
EU2-2SF | 1/4" | 53 | 22 | 21 | 19 |
EU2-3SF | 3/8" | 54 | 22 | 22 | 20 |
EU2-4SF | 1/2" | 56.5 | 22 | 24.5 | 25 |
Push To Connect, Standard Hose Barb | |||||
CODE | SIZE | L | D | L1 | SW |
EU2-2SH | 6MM | 59 | 22 | 16 | 19 |
EU2-3SH | 8MM | 61 | 22 | 18 | 19 |
EU2-4SH | 10MM | 63 | 22 | 20 | 19 |
