| Push To Connect, Male Pipe Thread | |||||
| CODE | SIZE | L | D | L1 | SW |
| EU3-2SM | 1/4" | 54.5 | 23 | 10.5 | 19 |
| EU3-3SM | 3/8" | 55 | 23 | 11 | 19 |
| EU3-4SM | 1/2" | 58.5 | 23 | 13.5 | 21 |
Material:
European interchangeable quick-connect connectors can complete the connection process in a few seconds through simple operations, saving valuable time and labor costs. At the same time, these connectors are highly secure and designed to maintain fluid integrity when connected, reducing the risk of leaks and ensuring safe system operation. These connectors are suitable for air transmission systems or liquid transmission systems, including a variety of liquids, such as water, chemicals, oils, etc., so they can play an important role in industrial and commercial fields, improving work efficiency and reducing possible losses. Products comply with European standards and undergo strict quality control during production and before shipment to ensure their quality. Users can fully trust and purchase our European interchange quick connectors.
Quick connect coupler with universal standard profile.
Interchangeable with the most popular connection nipples.
Modern CNC machine tools manufactured and performed
For ease assembling and time saving applications.
Operating Temperature:-10°C to +60°C
Operating Pressure: 0-16 bar
Interchangeability: GAV 4500, UNI Series, Euro Line
Detailed parameters

| Push To Connect, Male Pipe Thread | |||||
| CODE | SIZE | L | D | L1 | SW |
| EU3-2SM | 1/4" | 54.5 | 23 | 10.5 | 19 |
| EU3-3SM | 3/8" | 55 | 23 | 11 | 19 |
| EU3-4SM | 1/2" | 58.5 | 23 | 13.5 | 21 |

| Push To Connect, Female Pipe Thread | |||||
| CODE | SIZE | L | D | L1 | SW |
| EU3-2SF | 1/4" | 54 | 23 | 24.5 | 19 |
| EU3-3SF | 3/8" | 55 | 23 | 25.5 | 20 |
| EU3-4SF | 1/2" | 58.5 | 23 | 28 | 25 |

| Push To Connect, Standard Hose Barb | |||||
| CODE | SIZE | L | D | L1 | SW |
| EU3-2SH | 6MM | 61 | 23 | 16 | 19 |
| EU3-3SH | 8MM | 63 | 23 | 18 | 19 |
| EU3-4SH | 10MM | 65 | 23 | 20 | 19 |
